FORD RANGER PETROL

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  16.5
• Battery Charging Scenario 1 - Charge Time (Mins)
  390
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  2.3
• Battery Charging Scenario 2 - Charge Time (Mins)
  252
• Battery Charging Scenario 2 - Percentage Change
  0-100
• Battery Charging Scenario 2 - Power Supply - kW
  6.9
• Battery Charging Scenario 3 - Charge Time (Mins)
  Not Available
• Battery Charging Scenario 3 - Percentage Change
  Not Available
• Battery Charging Scenario 3 - Power Supply - kW
  Not Available
• Battery Charging Scenario 4 - Charge Time (Mins)
  Not Available
• Battery Charging Scenario 4 - Percentage Change
  Not Available
• Battery Charging Scenario 4 - Power Supply - kW
  Not Available
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Right Side Front
• Coupler/Connector Type
  Type 2
• Maximum Charging Rate - kW
  6.9
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  11.8
• WLTP - EC AC Weighted (kWh/100km) - Comb
  22.9
• WLTP - EC AC Weighted (miles/kWh) - Comb
  2.7
• WLTP - Equivalent AER (km) - Comb
  42
• WLTP - Equivalent AER (miles) - Comb
  26

Emissions - ICE

• CO
  Not Available
• HC
  Not Available
• HC+NOx
  Not Available
• Noise Level dB(A)
  Not Available
• NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6

Emissions - PHEV

• WLTP - CO2 Weighted (g/km) - Comb
  71

Engine and Drive Train

• Automatic Transmission
  Yes
• Catalytic Convertor
  Yes
• CC
  2261
• Cooling System
  WATER
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Engine Layout
  NORTH SOUTH
• Engine Make
  Not Available
• Fuel Delivery
  TWIN TURBO
• Fuel Type
  PETROL
• Gears
  10 SPEED
• Manual Transmission
  No
• Number of Valves
  16
• Valve gear
  DOHC

Fuel Consumption - ICE

• EC
  No

Fuel Consumption - PHEV

• WLTP - FC Weighted (l/100km) - Comb
  3.1
• WLTP - FC Weighted (mpg) - Comb
  91.1

General

• Alternative Fuel Qualifying
  Yes
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
  2.3
• Badge Power
  281
• Based On ID
  Not Available
• Chassis Engine Number
  Not Available
• Clutch
  SINGLE DRY PLATE
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Exhaust System
  CATALYTIC CONVERTER
• Front Brakes
  DISCS
• Front Suspension
  DOUBLE SUSPENSION
• Generation Mark
  4
• Ghost model for valuation purposes
  No
• Hand Brake
  REAR WHEELS
• Insurance Group 1
  Not Available
• Insurance Group 2
  Not Available
• Manufacturers Corrosion Perforation Guarantee - Years
  12
• Manufacturers Paintwork Guarantee - Years
  3
• NCAP Adult Occupant Protection %
  84
• NCAP Child Occupant Protection %
  90
• NCAP Overall Rating - Effective February 09
  5
• NCAP Overall Rating - LCV
  Not Available
• NCAP Pedestrian Protection %
  74
• NCAP Safety Assist %
  84
• Rear Brakes
  DRUM
• Rear Suspension
  LEAF SPRINGS
• Relative Height
  H1
• Relative Length
  L1
• Running Cost League Headings
  MEDIUM
• Service Interval Frequency - Months
  24
• Service Interval Mileage
  12500
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  60000
• Standard manufacturers warranty - Years
  3
• Steering
  PAS
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• 0 to 62
  9.2
• BHP
  281
• Engine Power KW
  207
• Engine Power RPM
  4600
• Engine Torque LBS.FT
  514
• Engine Torque MKG
  71.1
• Engine Torque NM
  697
• Engine Torque RPM
  2500

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Automatic Clutch
  Yes
• Plated 3rd Axle
  Not Available
• Plated 4th Axle
  Not Available
• Space Saver?
  No
• Tyre Make
  Not Available
• Tyre Size Front
  255/65 R17
• Tyre Size Rear
  255/65 R17
• Tyre Size Spare
  FULL SIZE
• Wheel Style
  Not Available
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Front Overhang
  865
• Height
  1871
• Height (including roof rails)
  Not Available
• Length
  5370
• Load Length
  1638
• Load Space Width Between Wheel Arches
  1224
• Lower Rear Door Width
  Not Available
• Rear Door Height
  Not Available
• Rear Overhang
  1215
• Side Load Door Height
  Not Available
• Side Load Door Width
  Not Available
• Turning Circle - Kerb to Kerb
  12.9
• Upper Rear Door Width
  Not Available
• Wheelbase
  3270
• Width (excluding mirrors)
  2015
• Width (including mirrors)
  2207

Weight and Capacities

• Boot Capacity Saloons
  Not Available
• Fuel Tank Capacity (Litres)
  70
• Gross Train Weight
  6600
• Gross Vehicle Weight
  3500
• Load Space Volume
  Not Available
• Luggage Capacity (Seats Down)
  Not Available
• Luggage Capacity (Seats Up)
  Not Available
• Luggage Capacity - 2nd Row Seats Removed
  Not Available
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• Luggage Capacity - 3rd Row Seats Down
  Not Available
• Luggage Capacity - 3rd Row Seats Removed
  Not Available
• Luggage Capacity - 3rd Row Seats Up
  Not Available
• Max. Roof Load
  Not Available
• Max. Towing Weight - Braked
  3500
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  2429
• No. of Seats
  5
• Payload
  1071
• Plated 2nd Axle
  2100
• Plated Front Axle
  1490
